Galvanized / G-30 / G-90
Reliance Sheet & Strip Company provides Galvanized steel products manufactured to ASTM-A653
(Commercial Steel-Type B) specifications. These steel sheets and coils are produced through a continuous hot-dip galvanizing process, where cold finished coils are immersed in molten zinc. As the steel exits the zinc bath, both the coating weight and surface appearance are precisely controlled to deliver a consistent, protective layer.
What Is Galvanized Steel?
Hot-dip galvanized steel features a protective zinc coating bonded to the steel surface, delivering superior corrosion resistance. The zinc barrier protects the base steel from rust and weather exposure, not only shielding the surface, but also sacrificing itself (through a process called galvanic action) to protect any exposed steel or sheared edges. This dual action makes galvanized steel ideal for demanding environments and projects requiring long-term durability.
Key Features and Benefits
Meets ASTM-A653 standards for commercial steel, guaranteeing consistent mechanical and chemical properties.
G-90 Zinc coating for maximum protection against corrosion.
Surface treated with passivating chemicals to prevent white rust.
Characteristic spangle finish for distinctive visual appeal, so size and shape may vary.
Highly formable and processable: coils and sheets can be shaped, welded, or soldered without the zinc coating flaking or breaking.
Suitable for indoor and outdoor applications requiring lasting strength and corrosion resistance.
G-90 Coating and Surface Quality
Reliance Sheet & Strip‘s galvanized steel is supplied with a G-90 coating designation, meaning the combined zinc coating on both sides totals at least 0.90 ounces per square foot, the industry standard for reliable, exterior-grade rust protection. After coating, our sheets undergo a chemical passivation treatment to further inhibit the formation of white rust. The surface is typically marked by “spangles,” unique flowery crystalline patterns whose size and shape may vary between sheets.
RSS Standard Stock Inventory – Galvanized G90 Steel
Thicknesses: 26 Gauge through 10 Gauge
Widths: 36”, 48”, 60”
Grades: A653 CS, RoHS Compliant
Domestically produced material including 100% melted & manufactured available.
G-30 Coating and Surface Quality
Reliance Sheet & Strip supplies G-30, a precision-engineered steel product developed as a superior alternative to electro-galvanized steel. Created in collaboration with computer industry engineers, G-30 is designed specifically for demanding electronic and computer chassis applications that require exceptional weldability, corrosion protection, formability, conductivity, and paintability.
G-30 coating weight (0.30 ounces of zinc per square foot in total) provides a cost-effective level of corrosion resistance well-suited for indoor, dry, or lightly corrosive environments.
Extra smooth, zero-spangle surface for enhanced appearance and optimal paint adhesion.
Passivated finish meets ROHS compliance standards for electronics and sensitive manufacturing.
Dry surface, but specially treated to inhibit white rust and maintain surface conductivity.
RSS Standard Stock Inventory – Galvanized G30 Steel
Thicknesses: 22 Gauge through 14 Gauge
Widths: 36”, 48”
Grades: A653 CS/FS, Extra Smooth Finish, RoHS Compliant
Domestically produced material including 100% melted & manufactured available.
Applications
Galvanized steel from Reliance Sheet & Strip is trusted for:
G-90
Agriculture equipment
Electrical enclosures
Automotive and machinery parts
General manufacturing
G-30
Computer and electronic enclosures
Data center racking systems
Electrical panel convers and housings
Painted office furniture and appliance components
Precision-formed indoor equipment
Lighting fixtures
For expert guidance, customized sizing, or more information about galvanized steel options, contact the Reliance Sheet & Strip team, your dependable supplier for rust-resistant steel products.
Custom Processing and Local Delivery
At Reliance Sheet & Strip Company, your needs always come first.
